Alliance Laundry Systems HF900 - Manual (Page 16)

16
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 66,4 kg 146.39 lb.
1:10 73 kg 160.94 lb.
1:9 81,1 kg 178.79 lb.
Cylinder
Diameter 1095 mm 43.11 inch
Depth 775 mm 30.51 inch
Volume 730 Lit 25.78 ft³
Cabinet
Height 2100 mm 82.68 inch
Width 1300 mm 51.18 inch
Depth 1628 mm 64.09 inch
Front loading
Diameter door opening 622 mm 24.49 inch
Height under door 603 mm 23.74 inch
To center 992,5 mm 39.07 inch
Speed
Wash 10 - 50 tr/min - RPM
Spin 250 - 750 tr/min - RPM
G-factor
High spin 350
Dynamic bottom load (N/Hz)
4960/13
Motor (3-phase)
4p. 1470 tr/min 11,5 kW / 15,42 HP
Drain valve
2x3"
Water supply
Hard, soft, warm water 1x3/4" + 3x1"
Steam connection
Steam connection 3/4"
Heating
Electrical 230/400 V 27 kW
Electrical 400V 27 kW - 36 kW
Steam 6 bar
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 2250x1400x1800 mm - 88.58x55.12x70.87 inch
Weight
Net 2250 kg 4960.40 lb.
Gross 2350 kg 5180.86 lb.
Technical data HF730, IHF730, IHF165, CHF165
