Alliance Laundry Systems HF900 - Manual (Page 18)

18
3
METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 81,8 kg 180.34 lb.
1:10 90 kg 198.42 lb.
1:9 100 kg 220.46 lb.
Cylinder
Diameter 1095 mm 43.11 inch
Depth 957 mm 37.68 inch
Volume 900 Lit 31.78 ft³
Cabinet
Height 2100 mm 82.68 inch
Width 1300 mm 51.18 inch
Depth 1808 mm 71.18 inch
Front loading
Diameter door opening 622 mm 24.49 inch
Height under door 603 mm 23.74 inch
To center 992,5 mm 39.07 inch
Speed
Wash 10 - 50 tr/min - RPM
Spin 250 - 750 tr/min - RPM
G-factor
High spin 350
Dynamic bottom load (N/Hz)
6100/13
Motor (3-phase)
4p. 1470 tr/min 11,5 kW / 15,42 HP
Drain valve
2x3"
Water supply
Hard, soft, warm water 1x3/4" + 3x1"
Steam connection
Steam connection 3/4"
Heating
Electrical 230/400 V 27 kW
Electrical 400V 27 kW - 36 kW
Steam 6 bar
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 2250x1630x2100 mm - 88.58x64.17x82.68 inch
Weight
Net 2900 kg 6393.41 lb.
Gross 3000 kg 6613.87 lb.
Technical data HF900, IHF900
