METRIC US
Capacity (dry weight) Ratio [kg/Lit]
1:11 52,3 kg 115.30 lb.
1:10 57,5 kg 126.77 lb.
1:9 63,8 kg 140.65 lb.
Cylinder
Diameter 980 mm 38.58 inch
Depth 775 mm 30.51 inch
Volume 575 Lit 20.31 ft³
Cabinet
Height 1920 mm 75.59 inch
Width 1200 mm 47.24 inch
Depth 1510 mm 59.45 inch
Front loading
Diameter door opening 500 mm 19.69 inch
Height under door 638 mm 25.12 inch
To center 960 mm 37.80 inch
Speed
Wash 10 - 50 tr/min - RPM
Spin 250 - 800 tr/min - RPM
G-factor
High spin 350
Dynamic bottom load (N/Hz)
3900/13
Motor (3-phase)
4p. 1470 tr/min 7,5 kW / 10,05 HP
Drain valve
3"
Water supply
Hard, soft, warm water 4x3/4"
Steam connection
Steam connection 1/2"
Heating
Electrical 230/400 V 27 kW
Electrical 400V 27 - 36 kW
Steam 6 bar
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm - inch 2130x1300x1630 mm - 83.86x51.18x64.17 inch
Weight
Net 1787 kg 3939.66 lb.
Gross 1887 kg 4160.12 Ib.
Technical data HF575, IHF575, IHF135, CHF135
