210 [8.27]
177.5 [6.99
]
210 [8.27]
701 [27.6
]
102 [4.02
]
162 [6.38
]
222 [8.74
]
113 [4.45]
173 [6.81]
233 [9.18]
303 [11.93]
162 [6.38
]
A
A B
C
G H
I
83 [3.27]
342 [13.46
]
J J
257 [10.12
]
486 [19.13
]
E
D
F
G
192
0 [7
5.5
9]
962
[3
7.87
]
1034 [40.71]
1200 [47.24] 83 [3.27] 83 [3.27]
638
[2
5.12
]
1010 [39.76]
1100 [43.31] 45 [1.77] 45 [1.77]
56.5 [2.23]
156.5 [6.16]
1283 [50.51]
26.5 [1.04]
3
13
Dimensions HF455, IHF455, IHF100, CHF100
 A. Soft water connection 3/4"
 B. Warm water connection 3/4"
 C. Hard water connection 3/4"
 D. Electrical connection
 E. Electrical connection clamps
 F. Main switch
 G. Ventilation cabinet
 H. Ventilation
 I. Steam connection 1/2"
 J. Drain valve
Legend: metric mm [inches]
