3
012-04367E Basic Electricity
VOM:
The Volt-Ohm-Meter or VOM is a multiple scale, multiple
function meter (such as the PASCO SB-9623 Analog
Multimeter), typically measuring voltage and resistance,
and often current, too. These usually have a meter move-
ment, and may select different functions and scales by
means of a rotating switch on the front of the unit.
Advantages: VOM’s may exist in your laboratory and
thus be readily accessible. A single meter may be used to
make a variety of measurements rather than needing
several meters.
Disadvantages: VOM’s may be difficult for beginning
students to learn to read, having multiple scales corre-
sponding to different settings. VOM’s are powered by
batteries for their resistance function, and thus must be
checked to insure the batteries are working well. Typi-
cally, VOM’s may have input resistances of 30,000
Ω
on
the lowest voltage range, the range that is most often used
in these experiments. For resistances in excess of
1,000
Ω
, this low meter resistance affects circuit opera-
tion during the taking of readings, and thus is not usable
for the capacitor, diode and transistor labs.
DMM:
The Digital Multimeter or DMM is a multiple scale,
multiple function meter (such as the PASCO SB-9624
Basic Digital Multimeter or the SE-9589 General Purpose
DMM), typically measuring voltage and resistance, and
often current, too. These have a digital readout, often
with an LCD (Liquid Crystal Display). Different func-
tions and scales are selected with either a rotating switch
or with a series of push-button switches.
Advantages: DMM’s are easily read, and with their
typically high input impedances (>10
6 Ω
) give good results
for circuits having high resistance. Students learn to read
DMM’s quickly and make fewer errors reading values.
Reasonable quality DMM’s can be purchased for $60 or
less. PASCO strongly recommends the use of DMM’s.
Disadvantages: DMM’s also require the use of a battery,
although the lifetime of an alkaline battery in a DMM is
quite long. The battery is used on all scales and func-
tions. Most DMM’s give the maximum reading on the
selector (i.e., under voltage, “2” means 2-volt maximum,
actually 1.99 volt maximum). This may be confusing to
some students.
VTVM:
The Vacuum Tube Voltmeter or VTVM is a multiple
scale, multiple function meter, typically measuring
voltage and resistance. They do not usually measure
current. The meter is an analog one, with a variety of
scales, selected with a rotating switch on the front of the
meter.
Advantages: VTVM’s have high input resistances, on
the order of 10
6 Ω
or greater. By measuring the voltage
across a known resistance, current can be measured with
a VTVM.
Disadvantages: VTVM’s have multiple scales. Students
need practice to avoid the mistake of reading the incorrect
one. An internal battery provides the current for measur-
ing resistance, and needs to be replaced from time to time.
Grounding problems can occur when using more than one
VTVM to make multiple measurements in the same
circuit.
Panelmeters:
Individual meters, frequently obtained from scientific
supply houses, are available in the form of voltmeters,
ammeters, and galvanometers (such as PASCO’s
SE-9748 Voltmeter 5 V, 15 V , SE-9746 Ammeter 1 A,
5 A and SE-9749 Galvanometer ± 35 mV). In some
models, multiple scales are also available.
Advantages: Meters can be used which have the specific
range required in a specific experiment. This helps to
overcome student errors in reading.
Disadvantages: Using individual meters leads to errors
in choosing the correct one. With limited ranges, students
may find themselves needing to use another range and not
have a meter of that range available. Many of the
individual meters have low input impedances
(voltmeters) and large internal resistances (ammeters).
Ohmmeters are almost nonexistent in individual form.
Light Bulbs
The #14 bulbs are nominally rated at 2.5 V and 0.3 A.
However, due to relatively large variations allowed by
the manufacturer, the wattage of the bulbs may vary by
15 to 30%. Therefore, supposedly “identical” bulbs may
not shine with equal brightness in simple circuits.
Comments on Meters
