PASCO ES-8086 Discover Charge Set User Manual

Discover charge set

Table of contents

Document Outline

Discover Charge Set
- Model No. ES-8086
  - Equipment List
    - 1. Material sheets, 10 cm x 15 cm: Teflon, Styrene, Polyester, Wool, PVC
  - Introduction
  - Creating Charged Indicators
    - 1. Cut a 10 cm strip of transparent tape and fold one cm over on itself to make a handle. Avoid t...
    - 2. Label this tape T1.
    - 3. Stick the strip of tape to the tabletop.
    - 4. Cut a 9 cm strip of transparent tape and fold one cm over on itself to make a handle. Avoid to...
    - 5. Label this tape T2.
    - 6. Stick the second piece of tape directly on top of the first piece as shown.
    - 7. Grasp the lower tape (T1) and quickly pull up from the table. Avoid touching the tape except b...
    - 8. Quickly pull T2 away from T1, again trying not to touch either tape except by the handle.
    - 9. Stick each tape to the edge of a table with the handle hanging freely as shown.
    - 10. Through the above process, the lower tape (T1) is now negatively charged and the upper tape (...
    - 11. The charged indicators are now ready to use with the five materials.
  - Triboelectric Series
  - Discovering Charge
    - 1. Ask students to choose two of the materials.
    - 2. Place one sheet in each hand and rub together for 20 seconds as shown.
    - 3. Separate the materials and bring one near the negative indicator tape. Observe the behavior of...
    - 4. Bring the same material near the positive indicator tape. Observe the behavior of the tape.
    - 5. Record the charge of the 1st material.
    - 6. Bring the second material near the negative indicator tape. Observe the behavior of the tape.
    - 7. Bring the same material near the positive indicator tape. Observe the behavior of the tape.
    - 8. Record the charge of the 2nd material.
    - 9. Explain how the two materials became charged; include electrons in your explanation.
    - 10. Place these two materials in the triboelectric series based on their behavior when rubbed tog...
    - 11. Choose one new material and rub it against one of the materials already used.
    - 12. Repeat steps 2-10 for these two materials.
    - 13. Continue testing until all five materials are ranked within the triboelectric series.
  - Conclusions
    - 1. Explain how the materials become charged through their interaction with one another.
    - 2. Ask students to explain in detail their process for ranking the materials. This explanation ca...
  - Teacher Notes:
012-08899a_cvr.pdf
- Discover Charge Set
- Model No. ES-8086
  - Warranty
  - For a description of the product warranty, see the warranty description in the PASCO catalog.
012-08899a_txt.pdf
- Discover Charge Set
  - Model No. ES-8086
- Equipment List
  - 1. Material sheets, 10 cm x 15 cm: Teflon, Styrene, Polyester, Wool, PVC
- Introduction
- Creating Charged Indicators
  - 1. Cut a 10 cm strip of transparent tape and fold one cm over on itself to make a handle. Avoid t...
  - 2. Label this tape T1.
  - 3. Stick the strip of tape to the tabletop.
  - 4. Cut a 9 cm strip of transparent tape and fold one cm over on itself to make a handle. Avoid to...
  - 5. Label this tape T2.
  - 6. Stick the second piece of tape directly on top of the first piece as shown below.
  - 7. Grasp the lower tape (T1) and quickly pull up from the table. Avoid touching the tape except b...
  - 8. Quickly pull T2 away from T1, again trying not to touch either tape except by the handle.
  - 9. Stick each tape to the edge of a table with the handle hanging freely as shown below.
  - 10. Through the above process, the lower tape (T1) is now negatively charged and the upper tape (...
  - 11. Write a negative sign (-) on T1 and a positive sign (+) on T2.
  - 12. The charged indicators are now ready to use with the five materials.
- Triboelectric Series
- Discovering Charge
  - 1. Ask students to choose two of the materials.
  - 2. Place one sheet in each hand and rub together for 20 seconds as shown below.
  - 3. Separate the materials and bring one near the negative indicator tape. Observe the behavior of...
  - 4. Bring the same material near the positive indicator tape. Observe the behavior of the tape.
  - 5. Record the charge of the 1st material.
  - 6. Bring the second material near the negative indicator tape. Observe the behavior of the tape.
  - 7. Bring the same material near the positive indicator tape. Observe the behavior of the tape.
  - 8. Record the charge of the 2nd material.
  - 9. Explain how the two materials became charged; include electrons in your explanation.
  - 10. Place these two materials in the triboelectric series based on their behavior when rubbed tog...
  - 11. Choose one new material and rub it against one of the materials already used.
  - 12. Repeat steps 2-10 for these two materials.
  - 13. Continue testing until all five materials are ranked within the triboelectric series.
- Conclusions
  - 1. Explain how the materials become charged through their interaction with one another.
  - 2. Explain in detail the process for ranking the materials. This explanation can either be in par...
- Teacher Notes:
012-08899a_txt.pdf
- Discover Charge Set
  - Model No. ES-8086
- Equipment List
  - 1. Material sheets, 10 cm x 15 cm: Teflon, Styrene, Polyester, Wool, PVC
- Introduction
- Creating Charged Indicators
  - 1. Cut a 10 cm strip of transparent tape and fold one cm over on itself to make a handle. Avoid t...
  - 2. Label this tape T1.
  - 3. Stick the strip of tape to the tabletop.
  - 4. Cut a 9 cm strip of transparent tape and fold one cm over on itself to make a handle. Avoid to...
  - 5. Label this tape T2.
  - 6. Stick the second piece of tape directly on top of the first piece as shown below.
  - 7. Grasp the lower tape (T1) and quickly pull up from the table. Avoid touching the tape except b...
  - 8. Quickly pull T2 away from T1, again trying not to touch either tape except by the handle.
  - 9. Stick each tape to the edge of a table with the handle hanging freely as shown below.
  - 10. Through the above process, the lower tape (T1) is now negatively charged and the upper tape (...
  - 11. Write a negative sign (-) on T1 and a positive sign (+) on T2.
  - 12. The charged indicators are now ready to use with the five materials.
- Triboelectric Series
- Discovering Charge
  - 1. Ask students to choose two of the materials.
  - 2. Place one sheet in each hand and rub together for 20 seconds as shown below.
  - 3. Separate the materials and bring one near the negative indicator tape. Observe the behavior of...
  - 4. Bring the same material near the positive indicator tape. Observe the behavior of the tape.
  - 5. Record the charge of the 1st material.
  - 6. Bring the second material near the negative indicator tape. Observe the behavior of the tape.
  - 7. Bring the same material near the positive indicator tape. Observe the behavior of the tape.
  - 8. Record the charge of the 2nd material.
  - 9. Explain how the two materials became charged; include electrons in your explanation.
  - 10. Place these two materials in the triboelectric series based on their behavior when rubbed tog...
  - 11. Choose one new material and rub it against one of the materials already used.
  - 12. Repeat steps 2-10 for these two materials.
  - 13. Continue testing until all five materials are ranked within the triboelectric series.
- Conclusions
  - 1. Explain how the materials become charged through their interaction with one another.
  - 2. Explain in detail the process for ranking the materials. This explanation can either be in par...
- Teacher Notes:
