Induction Wand Model No. EM-8099
4 ®
Introduction
The PASCO EM-8099 Induction Wand is useful for demonstrations of
electromagnetic induction. It can be used in combination with the
PASCO EM-6711 Field Coil to a) verify Faraday’s Law and b)
measure the relationship between the magnitude of the induced
electromotive force and the angle of the magnetic field of a field coil
and a pickup coil.
1
Equipment Description
The 200-turn Induction Wand has a wire coil on one end and two
terminals at the other end. The terminals accommodate the banana
plug contacts, permitting easy connection to an electric circuit.
Specifications
Induction Wand
No. of turns 200 turns, #28 copper wire,
approximately 0.32 mm diameter
Coil dimensions inner diameter: 1.9 cm; outer
diameter 3.1 cm
Body material molded ABS plastic
Total wand length: 35.7 cm
Handle dimensions: width: 1.9 cm; height: 1.25 cm;
length: 31.5 cm
1
For an induction experiment, see Christopher C. Jones.
Faraday’s Law Apparatus for the Freshman Laboratory. Am. J
Physics. 1987; 55(12): 1148-1150.
CAUTION: Do not use
the wand at currents
exceeding 625 mA.
