PASCO PS-2001 PowerLink - Manual

PowerLink 012-08406B
1 ®
PowerLink
Model No. PS-2001
Equipment List
*Use Replacement Model Numbers to expedite replacement orders.
Introduction
The PowerLink is a three-sensor port USB Link with a built-in general purpose USB hub and
PDA connectivity. It uses power from either an AC adapter (included) or two alkaline C-cell
batteries. When the AC adapter is used, the PowerLink is always on and draws no power
from the batteries. Each sensor has a status LED to indicate an active connection.
Included Equipment Replacement
Model Number*
1. PowerLink Assembly 003-08405
2. USB Cable Assembly 514-016
3. AC Adapter to 5 VDC (not shown) 540-047
Additional Equipment Required Model Number
DataStudio Software, version 1.8 or higher See PASCO catalog.
USB-compatible computer Not for sale from PASCO.
PASPORT sensor Various, see PASCO
catalog.
1 2
