Instruction Manual
No. 012-08852A
IR Sensor
PS-2148
Introduction
The PASPORT IR Sensor measures infrared radiation intensity over a broad spectrum,
allowing students to study a variety of phenomena including blackbody radiation, the
Stefan-Boltzmann law, heat flow by radiation, solar radiance and non-contact temperature
measurement.
Included Equipment Part Number
IR Sensor PS-2148
Shutter with thumbscrew and washer 003-08860
Sensor Handle CI-9874 (4-pack)
Additional Equipment Required
PASPORT interface See PASCO catalog or www.pasco.com
DataStudio or DataStudio Lite
(required for computer-based data collection)
See PASCO catalog or www.pasco.com
DS Lite available for free download
Additional Equipment Recommended
PASPORT Extension Cord PS-2500
Aperture Bracket OS-8534
Thermal Cavity TD-8580
IR
L IG
H
T
PS-2148
Sensor Handle
IR Sensor
Shutter
Thumbscrew
& Washer
