R e s p i r a t i o n R a t e S e n s o r I n t r o d u ct io n
4
• Touch the icon under “Functions:” until it shows “Spe-
cial 1”.
• Touch the ‘period’ icon. The calculation changes to
show the following:
respirationrate=60/period(90,10,5,|)
where the vertical line before the last parentheses repre-
sents the blinking cursor. The period function has four
items: peak%, valley%, time interval, and data source.
The cursor is in the space where the data source is
placed.
• Touch the ‘Measurements’ icon. Touch ‘Relative Pres-
sure’ in the list. The calculation changes to show the fol-
lowing:
respirationrate=60/period(90,10,5,[Relative Pres-
sure(kPa)])
• Touch “Done”.
Specifications (PS-2114)
Suggested Activities
• Respiration Rate and Physical Activity
• Respiration Rate and Heart Rate
• Respiration Rate and Body Temperature
• Respiration Rate and Different Types of Activity
• Respiration Rate and Altitude
Note: When the belt is connected to the Relative Pressure
Sensor, the sensor measures the change in pressure in the air
bladder in the belt as the lungs expand and contract.
Although the pressure of the chest cavity causes pressure
against the belt, the pressure measured in the belt is not the
actual pressure in the lungs.
Do not use the Relative Pressure Sensor around
liquids. Do not get liquids into the squeeze bulb,
tubing, or bladder.
Technical Support
For assistance with any PASCO product, contact PASCO at:
For the latest information about the Respiration Rate Sensor,
visit the PASCO web site at www.pasco.com and enter
“PS-2133” in the Search window.
Limited Warranty For a description of the product warranty, see the
PASCO catalog. Copyright The PASCO scientific Instruction Sheet
is copyrighted with all rights reserved. Permission is granted to
non-profit educational institutions for reproduction of any part of this
manual, providing the reproductions are used only in their laborato-
ries and classrooms, and are not sold for profit. Reproduction under
any other circumstances, without the written consent of PASCO sci-
entific, is prohibited. Trademarks PASCO, PASCO Capstone,
PASPORT, SPARK Science Learning System, SPARK SLS, and
SPARKvue are trademarks or registered trademarks of PASCO sci-
entific, in the United States and/or in other countries. For more infor-
mation visit www.pasco.com/legal.
Product End of Life Disposal Instructions:
This electronic product is subject to disposal and recycling
regulations that vary by country and region. It is your
responsibility to recycle your electronic equipment per your
local environmental laws and regulations to ensure that it
will be recycled in a manner that protects human health and
the environment. To find out where you can drop off your
waste equipment for recycling, please contact your local
waste recycle/disposal service, or the place where you pur-
chased the product.
The European Union WEEE (Waste Elec-
tronic and Electrical Equipment) symbol
(to the right) and on the product or its
packaging indicates that this product must
not be disposed of in a standard waste con-
tainer.
Item Value
Range: 0 to 10 kPa
Accuracy: ±0.05 kPa
Resolution 0.001 kPa
Maximum Sample Rate 20 Hz
Repeatability 0.01 kPa
Operating Temperature 0 to 40 °C
Relative Humidity Range 5 to 95%, non-condensing
