012-08925A
ELVIS Adapters
3
Chart: Connection of ScienceWorkshop Motion Sensors
ELVIS I/O
Digital Adapter I/O
DC Power Supplies
Power Ground
GND
Digital Port #1 Power Ground
GROUND
CNTR0_OUT
Counter #0 Output
SIG1
TTL Signal for Digital Port #1
DC Power Supplies
+ 5 V Power Supply Output
+5
+ 5 V Sensor Power Input
+5 V
DC Power Supplies
+ 5 V Power Supply Output
+ 5
+ 5 V Sensor Power Input
+5 V
CNTR1_GATE
Counter #1 Gate Input
SIG2
TTL Signal for Digital Port #2
DC Power Supplies
Power Ground
GND
Digital Port #2 Power GND
GROUND
Chart: Connection of ScienceWorkshop Photogates
ELVIS I/O
Digital Adapter I/O
DC Power Supplies
Power Ground
GND
Digital Port #1 Power Ground
GROUND
CNTR0_SOURCE
Counter #0 Source
SIG1
TTL Signal for Digital Port #1
DC Power Supplies
+ 5 V Power Supply Output
+5
+ 5 V Sensor Power Input
+5 V
