Format of custom forms #1 and #2

If FORM1 or FORM2 is selected, it can be changed by the user using a selection of
available data. By default the 2 forms are the same as the standard form unless
changed by the user as below.

When FORM 1 or FORM 2 is selected the user can set the information to be printed on
each line of the form. Pressing the [Up] or [Down] keys will cycle through the options
available. The options are:

INST ID

Instrument ID number

SER No

Serial Number

TIME

Time

DATE

Date

NET

Net Weight (Gross weight – Tare Weight)

GROSS

Gross Weight

TARE

Tare Weight

UNIT

Unit weight in parts counting mode

COUNT

Number of items in parts counting mode

REF

100% weight in percent weighing mode

PERCENT

Percentage of reference weight in percent weighing

LO LIMIT

Low Limit when check weighing

HI LIM

High Limit when check weighing

Cr Lf

Inserts a blank line

END

Signifies the end of the report

When END is entered the display returns to the RS‐232 Sub‐menu

Enter the data to be printed on the first line by pressing the [Up] or [Down] key
to cycle through the options. If the current information is OK then press the
[Setup/Enter] key to move to the next line.

e.g. “LINE No1” “DATE” ‐ prints date

Select a code for one of the preset data formats as detailed above.
