Dings Dynamics Group 56C 405TC frame - Manual (Page 4)

• Conforms to MIL-B-16392 specifications
• Aluminum bronze stationary disc
• Primer & top coat per TT-P-645
& MIL-DTL-15090
• NEMA 4/ IP56 Enclosure
• Ductile iron construction
• Non-maintained
(Deadman) release
• Torque adjustable
• No disassembly required
for mounting
Torque
lb-ft. Model #
Wt.
Lbs.
Thermal
Capacity
HPS/MIN
Inertia
WK
2
Lb.Ft.
2
List
Price
3 5-71003-42 54 11 0.028 $8,300
10 5-71010-42 54 11 0.028 $8,600
15 5-71015-42 54 11 0.028 $8,700
25 5-72025-42 58 12 0.051 $8,850
35 5-72035-42 58 12 0.051 $8.975
50 5-73050-42 62 13 0.075 $9,200
75 5-74075-42 66 14 0.099 $9,550
70 Series
Frame Sizes 182TC
through 256TC
Torque
lb-ft. Model #
Wt.
Lbs.
Thermal
Capacity
HPS/MIN
Inertia
WK 2
Lb.Ft.
2
List
Price
25 5-81025-27 80 15 0.084 $8,950
35 5-81035-27 80 15 0.084 $9,075
50 5-82050-27 85 17 0.158 $9,950
75 5-83075-27 90 19 0.233 $10,450
90 5-83090-27 90 19 0.233 $11,150
135 5-84135-27 97 21 0.309 $16,000
180 5-85180-27 104 21 0.384 $17,500
80 Series
Frame Sizes 284TC
and 286TC
