Dings Dynamics Group 70 Series End Mount NEMA 4 Standard - Manual (Page 3)

2
ITEM
NO.
PCS.
REQ’D DESCRIPTION PART NO.
1 1 Bracket W/Studs – 1Disc L070078-001
1 1 Bracket W/Studs – 2 Disc L070078-002
1 1 Bracket W/Studs – 3 Disc L070078-003
1 1 Bracket W/Studs – 4 Disc L070078-004
2 2 Stud – 1 Disc G070213-001
2 2 Stud – 2 Disc G070213-002
2 2 Stud – 3 Disc G070213-003
2 2 Stud – 4 Disc G070213-004
3 (1) Rotating Friction Disc H070103-006
4 (2) Stationary Disc K070485-001
5 2 Torque Spring (Blue) G070011-001
5 2 Torque Spring (Silver) G070012-001
5 2 Torque Spring (Red) G070019-001
6 1 Cap Plug W008003-001
7 2 Manual Release Rod G070001-002
8 2 Manual Release Spring G060010-001
9 2 Manual Release Stop Screw G060029-001
10 2 Lockwasher W004007-007
11 As Req’d Manual Release Shims W004004-004
12 2 Washer W004004-003
13 2 ESNA Nut W003001-022
14 2 Washer W004004-001
15 2 Hex Nut W003003-023
16 2 Drive Screw W001012-048
17 2 Cover Bolt W001039-001
18 1 Cover K070500-001
19 1 Instruction Label (Not shown) H070358-001
20 2 ESNA Nut W003001-020
21 2 Ext. Tooth Lockwasher W004008-006
22 1 Hub *
23 2 Button Plug W008001-007
25 1 Name Plate K060473-001
28 1 Pressure Plate Assembly K070045-001
29 1 Magnet Assembly with Coils K070335-*
30 1 Magnet Plate w/o Coils, 3p K070024-001
30a 1 Magnet Plate w/o Coils, 1p K070027-001
31 * Magnet Coil *
32 2 Insulating Washer, 3p G070037-001
32a 2 Insulating Washer, 1p G070029-001
33 2 Shading Coil, 1p only G070032-001
(1) N b f t ti di i h d di it f M d l N
Table 1. Parts List
(1) Number of rotating discs is shown as second digit of Model Number.
Example: 4-72025-103
(2) Number of stationary discs is one less than the number of rotating discs.
* Part number will vary depending on voltage, frequency, bore size, etc.
