Dings Dynamics Group 70 Series End Mount NEMA 2 Standard - Manual (Page 3)

2
Table 1. Parts List
ITEM
NO.
PCS.
REQ’D
DESCRIPTION PART NO.
1 1 Bracket – 1 Disc L070078-001
1 1 Bracket – 2 Disc L070078-002
1 1 Bracket – 3 Disc L070078-003
1 1 Bracket – 4 Disc L070078-004
2 2 Stud – 1 Disc G070213-001
2 2 Stud – 2 Disc G070213-002
2 2 Stud – 3 Disc G070213-003
2 2 Stud – 4 Disc G070213-004
3 (1) Rotating Friction Disc H070103-007
4 (2) Stationary disc K070485-001
5 2 Torque Spring (Blue) for 10 lb-ft brake G070011-001
5 2 Torque Spring (Silver) for 15, 35, 50, & 75 lb-ft brake G070012-001
5 2 Torque Spring (Red) for 25 lb-ft brake G070019-001
6 1 Cap Plug W008003-001
7 2 Manual Release Rod G070001-002
8 2 Manual Release Spring G060010-001
9 2 Manual Release Stop Screw G060029-001
10 2 Lockwasher W004007-007
11 As Req’d Manual Release Shims W004004-004
12 2 Washer W004004-003
13 2 ESNA Nut W003001-022
14 2 Washer W004004-001
15 2 Hex Nut W003003-023
16 2 Drive Screw W001012-048
17 2 Cover Screw W001002-103
18 1 Cover K070471-002
19 1 Instruction Label (Not shown) H060058-002
20 2 ESNA Nut W003001-020
21 2 Ext. Tooth Lockwasher W004008-006
22 1 Hub *
23 2 Button Plug W008001-007
25 1 Nameplate K060473-001
28 1 Pressure Plate Assembly K070045-001
29 1 Magnet Assembly with Coils K070097-*
30 1 Magnet Plate w/o Coils, 3 phase K070024-001
30a 1 Magnet Plate w/o Coils, single phase K070027-001
31 * Magnet Coil *
32 2 Insulating Washer, 3 phase G070037-001
32a 2 Insulating Washer, single phase G070029-001
33 2 Shading Coil, single phase only G070032-001
(1) Number of rotating discs is shown as second digit of Model No.
Example: 6-72025-96
(2) Number of stationary discs is one less than the number of rotating discs.
* Part number will vary depending on voltage, frequency, bore size, etc.
