List of Dings Brake Models
Listed by Underwriter’s Laboratories, Inc.
For Hazardous Locations,
Class I, Group C and D
Class II, Group E, F and G
Temperature Code - T3C
Thermal
Capacity
Torque HP
Model No.* Ft. Lbs. Sec./Min.
8-61001-xx 1.5 7
8-61003-xx 3 7
8-62006-xx 6 8
8-63010-xx 10 9
8-63015-xx 15 9
For Direct Mounting to
Motor “C” Face.
NEMA Motor Frame Sizes
56C, 66C, 143TC, 145TC
Thermal
Capacity
Torque HP
Model No.* Ft. Lbs. Sec./Min.
A8-61001-xx 1.5 7
A8-61003-xx 3 7
A8-62006-xx 6 8
A8-63010-xx 10 9
A8-63015-xx 15 9
For Adapter Mounting to
Motor “C” Face.
NEMA Motor Frame Sizes
182TC, 184TC, 213TC,
215TC, 245TC, 256TC
Thermal
Capacity
Torque HP
Model No.* Ft. Lbs. Sec./Min.
F8-61001-xx 1.5 7
F8-61003-xx 3 7
F8-62006-xx 6 8
F8-63010-xx 10 9
F8-63015-xx 15 9
For Foot Mounting
* Complete Model Number by Adding
Suffix -66B for Cast Iron Housing
Suffix -67B for Aluminum
