Table 2. Parts List
4
* = See Table 1 for complete model number explanation
Note 1. Part number is dependent on voltage and torque of brake - Contact Factory for part number.
Note 2. Part number is dependent on model configuration of brake - Contact Factory for part number.
ITEM
NO.
QUANTITY
DESCRIPTION
PART
NUMBER
Model Number
61003-560* 61006-560* 62010-560*
1 1 1 1 Assembly, Bracket Plate with Studs K060637-004
3 2 2 2 Stud H060667-001
4 1 1 1 Bolt, Carriage, Pivot W001044-026
5 1 1 1 Washer, Spacer G061046-001
6 1 1 1 Lockwasher W004006-007
7 3 3 3 Nut, Hex W003002-002
8 2 2 2 Spring, Pressure Arm Return G061047-001
9 4 4 4 Washer, Flat W004013-017
10 1 1 1 Spring, Pivot G061048-001
11 1 1 2 Disc, Friction H060157
12 1 1 2 Disc, Stationary H060665-001
13 1 1 – Bar, Spacer H060675-001
14 1 1 1 Arm, Pressure K060604-001
15 1 1 1 Nut, Pivot G061041-001
16 1 1 1 Nut, Nylock, Full W003013-003
17 1 1 1 Assembly, Armature H060678-002
18 2 – – Spring, Torque (White) G061049-001
18 – 2 – Spring, Torque (Purple) G061051-001
18 – – 2 Spring, Torque (Yellow) G050077-001
19 6 6 6 Nut, Nylock, Thin W003001-015
20 2 2 2 Absorber, Shock G060310-001
21 1 1 1 Assembly, Magnet Note 1
Items 22 & 23 only available on models with external wire outlet
22 1 1 1 Bracket, External Wire Outlet H060676-001
23 2 2 2 Screw, External Wire Outlet Bracket W001045-085
Items 24 through 28 only available on models with a manual release
24 1 1 1 Lever, Manual Release H060673-001
25 1 1 1 Bracket, Manual Release H060674-001
26 1 – – Spring, Manual Release Return (Yellow) G061078-001
26 – 1 1 Spring, Manual Release Return (Silver) G061052-001
27 2 2 2 Screw, Manual Release Assembly W001045-043
28 2 2 2 Label, Manual Release (not shown) G060859-001
29 1 1 1 Cover Note 2
30 1 1 1 Assembly, Hub, 5/8" Bore K060611-032
30 1 1 1 Assembly, Hub, 7/8" Bore K060611-034
31 1 1 1 Key, Machine, 3/16” Square G061053-002
32 1 1 1 Nameplate (not shown) per order
33 1 1 1 Operating Instructions and Parts Manual BK4684
SPECIFICATIONS
MOTOR FRAMES . . . . . . . . . . . . . . . . . . . . .56C Frame
HOUSING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Steel
DUTY
. . . . . . . . . . . . . . . .Rated for continuous duty
VOLTAGES . . . . . . . . . . . . .All standard NEMA single
phase voltages and frequencies
available. Other voltages and frequencies .
are optional.
MOUNTING . . . . . . . . . . . . . Brake is for mounting to
NEMA “C” motor flanges.
Brake is for horizontal mounting.
TORQUE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10 lb-ft
