Diamond Products C740TE User Manual
Page 9
Frame Upright Assembly #6012128
ITEM
PART NO.
QTY.
DESCRIPTION
1
6012138
1
Frame Upright Weldment
2
2900013
2
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
3
2900014
14
Flat Washer, 3/8" SAE
4
2900018
2
Lock Nut, 3/8-16 Nylon
5
2900499
4
Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
6
2900058
4
Flat Washer, 1/2" SAE
7
2900026
4
Lock Nut, 1/2-13 Nylon
8
6010014
2
Handle Bar, 36" Long
9
2500636
2
Handle Grip
10
2900430
2
Hand Lock Knob, 1/2-13 x 1-1/2"
11
2503704
1
Wrench, 15/16" Combination
12
2501923
1
L-Key, 3/8" Hex
13
2500462
6
Plug, 3/8" Hole
14
2501287
1
Plug, 7/16" Hole
15
2500549
1
Plug, 7/8" Hole
16
2500489
2
Plug, 1" Hole
17
2501146
1
Plug, 1-1/4" Hole
18
1800169
1
Serial Number Plate, US
19
2900096
2
Rivet, 3/32" Dia.
20
1800377
1
Serial Number Plate, CE
21
2900287
2
Rivet, 1/8" Dia.
22
2501427
1
Cable Cleat
23
2900483
2
Tap Screw, Flat Hd., #10-24 x 1"
24
6010166
1
Gate Cover Bar
25
2900144
2
Cap Screw, Hex Hd., 1/4-20 x 3/4"
26
2900010
2
Lock Nut, 1/4-20 Nylon
27
6013042
1
Saw Weight, 57 Pound
28
2900521
4
Tap Bolt, Hex Hd., 3/8-16 x 2-1/2"
29
2900006
8
Lock Washer, 3/8" Split
30
2900033
8
Hex Nut, 3/8-16
9
