Diamond Products C740TE User Manual
Page 53
20" Blade Guard Assembly #6010602
ITEM
PART NO.
QTY.
DESCRIPTION
1
6010603
1
20" Blade Guard Front & Rear Only
2
6010081
1
Splash Flap
3
2900008
2
Cap Screw, Hex Hd., 1/4-20 x 1"
4
2900009
4
Flat Washer, 1/4" SAE
5
2900083
2
Fender Washer, 1/4" x 1-1/4"
6
2900010
8
Lock Nut, 1/4-20 Nylon
7
6010261
1
Water Manifold
8
2500830
1
Water Manifold Gasket
9
2900294
2
Cap Screw, Hex Hd., 1/4-20 x 2"
10
3200001
3
Plug, 1/8" NPT
11
3200002
1
Fitting, 3/8" M. Pipe to 3/4" M. Garden
12
2900278
1
Lanyard with Lock Pin
13
6010085
2
Water Tube for 20" Guard
14
6048155
2
Water Tube Clamp
15
2900020
4
Cap Screw, Flat Hd., 1/4-20 x 3/4"
16
1800001
1
Warning Label
17
6010251
1
Hinge Assembly for 20" Guard
ITEM
PART NO.
QTY.
DESCRIPTION
18
2500270
1
Blade Guard Hinge
19
2900144
6
Cap Screw, Hex Hd., 1/4-20 x 3/4"
20
2900010
6
Lock Nut, 1/4-20 Nylon
53
