Diamond Products C740TE User Manual
Page 43
40hp Motor Mount Assembly #6012111
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600185
1
Motor, 40hp Lincoln
2
6010011
1
Engine Base Weldment
3
6012034
2
Motor Spacer
4
6012035
2
Motor Connect Spacer
5
6012108
4
Spacer, 1/2"
6
2900002
13
Flat Washer, 5/8" SAE
7
2900113
5
Lock Washer, 5/8" Split
8
2900135
9
Lock Nut, 5/8-11 Nylon
9
2900512
1
Cap Screw, Hex Hd., 5/8-11 x 1-1/4"
10
2900527
4
Cap Screw, Hex Hd., 5/8-11 x 2-1/2"
11
2900195
1
Cap Screw, Hex Hd., 5/8-11 x 3"
12
2900099
4
Cap Screw, Hex Hd., 5/8-11 x 3-1/2"
13
2900385
2
Set Screw, Sq. Hd., 5/8-11 x 8"
14
2900112
2
Hex Nut, 5/8-11
15
2900446
2
Swivel Pad Nut, 5/8-11
16
6010012
1
Frame Lift
17
6010013
1
Frame Lift Brace
18
2900721
3
Flat Washer, 5/8" USS Hardened
19
2900147
2
Cap Screw, Hex Hd., 5/8-11 x 1-3/4"
20
2900136
1
Cap Screw, Hex Hd., 5/8-11 x 2"
21
2900286
1
Cap Screw, Button Hd., 5/8-11 x 2"
22
2900013
1
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
23
2900005
1
Cap Screw, Hex Hd., 3/8-16 x 1"
24
2900018
2
Lock Nut, 3/8-16 Nylon
25
2500676
1
Motor Cord Adapter Plate
26
2900201
4
Rivet, 3/16" Dia.
27
2600250
1
Motor, 40hp Lincoln (575 Volt)
