MP Pumps FRX 100 - Manual

FRX 100
1" x 1" End Suction Centrifugal Pump
The FRX 100 316 stainless steel centrifugal pump is ideal for hard-to-
handle applications in the marine, commercial, and industrial markets.
All wetted components are 316 investment cast stainless steel providing
superior corrosion resistance when pumping chemical compounds. A
carbon / ceramic / Viton bellows shaft seal is standard with optional seals
available on request. The FRX 100 model is available with 1” NPT port
configurations. Pump rotation in 90° increments.
SPECIFICATIONS:
Suction and Discharge . . 1" NPT x 1" NPT
Materials of Construction 316 stainless steel
Flow . . . . . . . . . . . . . . . Up to 40 GPM
Head Feet . . . . . . . . . . . Up to 54'
Impeller . . . . . . . . . . . . 3.75" 316 stainless steel
Drive Options . . . . . . . . Close coupled 115V AC
Close coupled 12V DC
Close coupled 230V AC
Close coupled 24V DC
Seal . . . . . . . . . . . . . . . Carbon / ceramic / Viton bellows 150 PSI
Special seals upon request
Application:
Agricultural •
Commercial •
Industrial •
Marine •
