Imaging and Sensing Technology Corporation
QUADTEK
R600 VENTUS
Camera Interface R600CIA03A/R640CIA03A
Electrical Supply
Supply voltage ................................. 39V dc maximum from R600
control box
Compressed Air
Quality ............................................. Dry oil free instrument air
Supply pressure ............................... 4 to 10 bar g (58-145 psi)
Regulated pressure ......................... 2 bar minimum (30 psi)
Flow rate .......................................... 10dm 3 s-1 (21 SCFM)
Temperature ..................................... 20°C (68°F)
Cooling Water Supply (R640CIA03A only)
Quality ............................................. Clean/Sediment free
Supply pressure ............................... 4 bar (58 psi)
Flow rate .......................................... 15 litres per minute
Temperature ..................................... 35°C (95°F) (typically)
pH value ........................................... 6 to 8
Camera Control Box:
R600CBA03A / R600CBB03A / R600CRA03A
Electrical Supply
Supply voltage ................................. 100-120/200-240V ac 50/60Hz
Power ............................................... 50VA (max)
Supply tolerance .............................. ± 6% frequency
Output Signals
Video ................................................ Composite video 1V p-p PAL/NTSC
Over temperature alarm .................. Volt free NO/NC rated 240V ac 5A
Coolant fail alarm ............................ Volt free NO/NC rated 240V ac 5A
Indication
Green indicator ................................ Power on
Red indicator ................................... Over temperature with audible alarm
Red indicator ................................... Coolant fail with audible alarm
Camera Control Unit (Basic System)
R600CBD03A
Electrical Supply
Supply voltage ................................. 85-264 VAC; 47-63Hz
Power ............................................... 30w nominal
Output Signals
Video ................................................ Composite video IV P-P (PAL/NTSC)
Over Temperature Alarm ................. Voltage-free ND/NC rated 240 VAC SA
Environmental
Enclosure ......................................... IP55 or IP65
Ambient temperature ...................... 0° - 40°C
Relative humidity ............................. 0 - 80% non condensing
