OceanAire, Inc.
AIRBOSS (AIR COOLED)
MODEL PAC6034
460 VOLT 3 PHASE
August 1, 2001
T1
T2
T3
COMPRESSOR
COOLING
THERMOSTAT
TERMINAL
BLOCK
T1
T2
T3
L1
L2
L3
COMPRESSOR CONTACTOR
24 Volt Coil
EVAP
FAN
MOTOR
230 VOLT
CONDENSER
FAN
MOTOR
230 VOLT
L1
L2
T1
T2
EVAP MOTOR CONTACTOR
24 Volt Coil
24 Volt Coil
COND MOTOR CONTACTOR
CONDENSATE
PUMP
230 Volt
TERMINAL BLOCK
HI-LO FAN
SWITCH
HIGH
LOW
COM
HIGH PRESSURE
SWITCH
RUN
CAP
RUN
CAP
R
TANK FULL
LIGHT
JUMPER
460
VOLT
230
VOLT
230v POWER
TRANSFORMER
24v CONTROL
TRANSFORMER
230
VOLT
24
VOLT
T1
T2
L1
L2
L1
L2
L3
G
24 VOLT
LINE VOLTAGE
N.C.
N.O.
Wirepac6034
C
Airbossmanpg28
28
NC
