HIGH PRESSURE SWITCH
L2 FOR
208/230
L1 G
Oceanaire, Inc.
AIRBOSS, (AIR COOLED) MODELS
MODELS PAC10, 12, 18, 24, 36, WITH CONDENSATE PUMP
120/1/60 208/230/1/60
December 4, 2001
HIGH
RUN
CAP
NC
NO
COM
R
S
C
COMPRESSOR
SAFETY
SWITCH
RUN
CAP
L1
L2
T1
T2
Wirepacpump
G Y W RH B O RC
C Y G R TERMINAL
BLOCK
THERMOSTAT
COOLING ONLY
EVAPORATOR
FAN
MOTOR
HIGH-LO EVAPORATOR
FAN SWITCH
LOW
TERMINAL
BLOCK
COMPRESSOR/CONDENSER
CONTACTOR
EVAPORATOR MOTOR
CONTACTOR
N
R
24 Volt Coil
24 Volt Coil
CONDENSATE
PUMP
120 or 230 VOLT
TRANSFORMER
24 Volt
120 or 230
Volt
120/1/60
208/230/1/60
POWER CORD
RED LIGHT ON
CONTROL PANEL
LINE VOLTAGE
24 VOLT
L1
L2
T1
T2
HARD START
KIT
STANDARD ON
ONLY PAC1811
Hard Start Kit is factory installed
on the:
PAC1811
PAC6012
RUN
CAP
CONDENSER
FAN
MOTOR
