N.C.
N.O.
OceanAire, Inc.
AIRBOSS (AIR COOLED)
MODEL PAC3632
208/230 3 PHASE
G
Y
W
RH
B
O
RC
THERMOSTAT
COOLING ONLY
C
Y
G
R
TERMINAL
BLOCK
HI-LO FAN
SWITCH
HIGH
LO
RUN
CAPACITOR
EVAP.
FAN
MOTOR
L1
COMPRESSOR CONDENSER
CONTACTOR
HIGH PRESSURE SWITCH
R
L1
L2
L3
G
T1
T2
T3
L1
L2
L3
24 VOLT
LINE VOLTAGE
T1
T2
T3
COMPRESSOR
T
T2
L
EVAPORATOR
CONTACTOR
TERMINAL BLOCK
TRANSFORMER
C
RUN
CAPACITOR
COND.
FAN
MOTOR
NC
June 9, 2000
TANK FULL CUT-OUT SWITCH
wirepac3632
airbossmanpg25
25
