PART No. 6861M
BLACK (SMALLER)
ORANGE
YELLOW
COIL
WHITE
GREEN
PURPLE
RED (SMALL 18 GA)
BLACK (LARGE 14 GA)
RED (LARGE 14 GA)
TO BATTERY NEG (-)
TO BATTERY POS (+)
ORIGINAL COIL (+)
IGNITION KEY
NOT USED
TO 12 VOLTS
TO TACHOMETER
FROM MAG PICK-UP DIST
OR CRANK TRIGGER
®
PART No. 6861M
BLACK (SMALLER)
ORANGE
YELLOW
BLUE
COIL
WHITE
ALL OTHER WIRES
ORIGINALLY CONNECTED TO
THE COIL (-) TERMINAL
RING TERMINAL
CONNECTOR
RED
BLACK (LARGER)
RED (LARGER)
TO BATTERY NEG (-)
TO BATTERY POS (+)
TO TACHOMETER
MAGNETIC PICK-UP
(NOT USED)
AUX RPM LIMITER
ALL OTHER WIRES ORIGINALLY
CONNECTED TO THE COIL (+) SWITCH
+12 VOLTS FROM IGNITION SWITCH
®
PART No. 6861M
BLACK (SMALLER)
ORANGE
YELLOW
COIL
WHITE
Original coil wire from points
or electronic ignition amplifier
RED
BLACK (LARGER)
RED (LARGER)
TO BATTERY NEG (-)
TO BATTERY POS (+)
IGNITION KEY TO 12 VOLTS
TO TACHOMETER
MAGNETIC PICK-UP
(NOT USED)
Originally connected to coil (+) positive
www.malloryracing.com 6
Installing the HYFIRE ® 6AL2 with a Magnetic
Pickup Distributor or Crank Trigger
Installing the HYFIRE ® 6AL2
with an OEM Ignition Amplifer
Installing the HYFIRE ® 6AL2 with a Points/Amplifier
Style Ignition
FIGURE 8
FIGURE 9
FIGURE 10
H HY YF FIIR RE E 6 6A AL L2 2
H HY YF FIIR RE E 6 6A AL L2 2
H HY YF FIIR RE E 6 6A AL L2 2
