Page 5

S
ELECTING THE
N
UMBER OF
C
YLINDERS
1. With the unit powered off – press and hold
down the SAVE and S
HIFT
L
IGHT
buttons.
2. While holding those buttons down, apply power to the module.
The module will now display the (factory default) number
stored that represents the number of cylinders in an engine.
3. Use the
⇑
and
⇓
keys to select the number of cylinders for your engine.
4. When finished, press SAVE to store this new information and
put the module back into Control Mode operation.
Make this selection only once per installation.
When you do not make this selection your
3-S
TAGE
R
EV
-
LIMITER
uses the factory default.
CAUTION
:
It may take a few seconds for the module to save new values.
Be sure the display shows the engine RPM (default display) before turning the
module off. Powering off during a SAVE may cause you to lose stored values.
T
HE
SAVE B
UTTON
Pressing the SAVE button tells the R
EV
-
LIMITER
to store all of the values that have
been adjusted. They will be remembered, until they have been re-programmed and
over-written with the SAVE button. Turning off the unit does not erase values that
you have stored with the SAVE button.
You can adjust, and test, different settings, without storing values, by turning your
R
EV
-
LIMITER
off, without pressing SAVE. The unit remembers all of the last values
stored with the SAVE button, and restores them the next time it is powered on.
After you have completed the wiring (according to diagrams detailed later in this
ocument) you must do some basic configuration of your A
CCEL
3-Stage Rev-limiter.
S
ETTING
R
EASONABLE
R
EV
-
LIMITS
You should now set some reasonable values for your various rev-limits.
Enter Programming Mode by pressing the key for the function you wish to modify.
Exit Programming Mode by pressing that same key again.
i.e. Press P
EAK
RPM
to select your maximum engine speed.
The display will show the current value and a dot will flash in the upper left.
Use the
⇑
and
⇓
keys to adjust the value displayed in 100 RPM increments.
When finished press the P
EAK
RPM
key again.
The dot will stop flashing and the current engine speed will be displayed.
Do the same for all rev-limits and RPM-activated switches.
t is not necessary to exit Programming Mode to select a new function,
simply press the next value’s key.
After you have finished press SAVE to store all newly set values.
