Hypaject MK III Instructions
Issue 07: April 2001-04-23
6
8. Mould Vacuum On/Off Switch (option)
Switch down for ON, up for OFF
9. Mould Vacuum Isolator (option)
The mould vacuum isolation valve is placed horizontal to close and vertically to open.
Vacuum may be drawn via the self-swaging 6mm connector located on the rear of the
control cabinet.
10. Resin container Up/Down (Option)
Raises, lowers or holds the resin container
Homogeniser Top Band Heater
– Zone 2 (option)
11. Temperature controller. (See attached OMRON E5CK instruction sheets). Use Up/Down
keys to adjust heater temperature.
12. Heater ON/OFF switch
13. Circuit test button. Press to test fault circuit. Fault light will illuminate
14. Fault/Reset button. Indicates if fault present or heater over temperature. Press to re-set.
Homogeniser Bottom Band Heater
– Zone 3 (option)
Controls as above
Heated Outlet Hose
– Zone 1 (option)
Controls as above
Heated Melt Plate
– Zone 4 (option)
Controls as above
Heated Load Hose
– Zone 5 (option)
Controls as above
15. Internal Thermocouple readout. (option)
Indicates temperature sensed by thermocouple probe inside homogeniser
16. Homogeniser Pressure Readout (option)
ADW 15 unit indicating homogeniser pressure/vacuum (psi). 0-10v analogue output module
is incorporated as standard.
17. Homogeniser Weight Readout
ADW 15 unit indicating homogeniser weight (kg). 0-10v analogue output module is
incorporated as standard
18. Tare Button
Tares homogeniser weight.
19. Emergency Stop.
Cuts all electrical and pneumatic supplies. Pull up to restart.
