2 main unit overview (example) – Magnum Venus Plastech Hypaject MK III User Manual
Page 4
Hypaject MK III Instructions
Issue 07: April 2001-04-23
4
2.2 Main Unit overview (example)
The machine consists of the following components
1. Instrumentation and control panel
2. Heated Homogensier
3. Hand operated load valve
4. Resin heated outlet pipe work.
5. Resin Load Plate.
6. Inlet load pipe
4
3
5
2
6
1
