Page 11
Hypaject MK III Instructions
Issue 07: April 2001-04-23
11
4.0 Hypaject Operation
4.1 Resin Loading Procedure
1. Turn homogeniser pressure regulator fully anticlockwise to zero.
2. Ensure inject valve is closed.
3. Switch homogeniser vacuum/press
ure switch to ‘vacuum’ . Allow vacuum to rise to
maximum (Approximately 0.8/0.9 bar negative) as indicated on vacuum gauge.
4. Open hand operated diaphragm valve (turn anticlockwise) and load required quantity of
resin into Homogeniser. Close hand operated diaphragm valve when complete
(clockwise)
Caution
Do not load more than Homogeniser capacity will allow. (6000cc’s)
Note
It is suggested that a period of up to 5 minutes is allowed to elapse whilst the loaded
volume of resin is given further time to degas and to reach the pre set Homogeniser
zone temperature.
5. Turn vacuum/pressure switch to pressure
