Testing & Adjusting Manual

Rev. 01/2013

Page | 41

DAILY START UP CHECKLIST

ACTIVITIES MUST BE DONE IN THE SEQUENCE SHOWN, AND MUST BE TICKED OFF AS

COMPLETED. USE THIS CHECKLIST IN CONJUNCTION WITH THE OPERATING MANUAL FOR THE
ULTRAMAX UNIT. THIS SEQUENCE FOLLOWS ON FROM CHECKLIST 02 – START UP CHECKLIST

ACTIVITY

NO.

ACTIVITY

TICK WHEN
COMPLETED

Priority

Put on Respirator as specified for spray painting, Protective Clothing,
Eye Protection, and PVC Gloves

1

Check all hoses for damage.

2

Check all material supplies and fill or replace as needed.

3

Open main inlet air valve on the manifold.

4

Open recirculation valve on Catalyst Manifold

5

Remove the Pivot Pin from the UPS catalyst pump drive.

6

Manually pump the catalyst pump with the UPS drive, observe catalyst
returning to the catalyst jug, pump until the stream is air free.

7

Close recirculation valve on Catalyst Manifold.

8

Manually pump the catalyst pump with the UPS drive, bring catalyst
pressure to operating pressure 100 – 200 psi.

9

Replace the Pivot Pin into the UPS catalyst pump drive.

10

Adjust the catalyst percentage as required.

11

Check pump air regulator and gauge if needed use the regulator on the
manifold, slowly turn up the pump air pressure to the operating pressure, 30
– 50 psi. If a safety over ride valve in installed press and hold the priming
button while adjusting air pressure

12

Insert the Distribution Ring into the Mix Chamber locating rim.

13

Place mix housing Seal into the Mix Chamber locating rim.

14

Insert the Catalyst Injector and injector seal into the aperture in the
Distribution Ring. The spring goes into the gun block.

15

Place Mix Chamber and Catalyst Injector onto the front of the ProGun,
secure it with 2 screws.

16

Flush the Assembled mix chamber with solvent.

17

Install mixer and nozzle onto the mix chamber.


ABNORMAL CONDITIONS OBSERVED AND CORRECTED

Abnormal Condition

a

a

a

a when
corrected


OPERATORS NAME _______________________________________ DATE: ________________

SIGN OFF WHEN START UP CHECKS ARE COMPLETED : __________________________
