CCPLS-1000 Fluid Section Manual
Rev. 08/2012 Page | 24
Note: Use caution not to over tighten the lower Piston Rod as it will damage
the lip of the piston cups.
11. Apply a small amount of Loctite to the threads of the Priming Rod. Thread
Priming Rod into the Lower Piston Body.
Remove the Piston Rod from the vise and set aside.
Outlet Body Assembly –
1. Pack red grease (6706-2-1) into all of the V packing (CCPLS-1002) and Female
Compression Ring.
2.
Apply a light film of the proper lubrication to the inside of the packing area of the
Outlet Body.
3. Put together all four V Packing (CCPLS-1002) with the Male Compression Ring
on one end and the Female Compression Ring on the other.
4. Put this V Packing Assembly into the Outlet Body with the Male Compression
Ring going in first.
5. Apply a light film of the proper lubrication to the ten Wave Springs (CCPLS-1029)
and insert them into the Outlet Body onto the V Packing set.
6. Put Spring Support Ring (CCPLS-1005) into the Outlet Body on top of the Wave
Spring set.
7. Insert Rod Bushing (CCPLS-1001) into the Outlet Body onto the Spring Support
Ring.
8. Apply a little of the proper lubrication to the threads of Packing Nut (CCPLS-1006)
and thread it into the Outlet Body, just enough to contact the Rod Bushing
(CCPLS-1001), do not tighten at this point.
9. Apply a light film of the proper lubrication to the Displacement Rod and to the
Priming Rod.
10. Apply a light film of the proper lubrication to the Outlet Body where the Cylinder O-
ring will be installed.
Note: It would be helpful to put the Outlet Body into a vise at this point, if the fluid
section has been removed from the pump mount bracket.
