Parts drawings – Magnum Venus Plastech PATRIOT PAT-CCP-LS-0590-SS User Manual
Page 27
PAT-CCP-LS-0590 Chop Check Fluid Section Manual
Rev. 02/2012
Page | 27
Parts Drawings:
PAT-CCP-LS-0590
PATRIOT CHOP CHECK FLUID SECTION
PAT-CCP-LS-0590-SS
STAINLESS STEEL FLUID SECTION
PAT-CCP-2300
PATRIOT CHOP CHECK PUMP ASSEMBLY
PAT-CCP-PA-2300
PATRIOT CHOP CHECK PUMP ASSEMBLY
PAT-CCP-PA-1300-SS
STAINLESS STEEL PUMP ASSEMBLY
PAT-CCP-LS-0590-RK
REPAIR KIT – CHOP CHECK PUMP
