PAT-CCP-LS-0590 Chop Check Fluid Section Manual
Rev. 02/2012 Page | 16
Tools required:
• Red Grease (6706-2-1 1 oz) (6706-2-16 16 oz) (6706-2-32 32 oz)
• PAT-LS-OIL (PAT-LS-OIL-1GL 1Gallon) (PAT-LS-OIL-5GL 5 Gallon)
• Loctite™ 243 (removable) or equivalent Removable Thread Locking Compound
• 5/16-inch Hex Wrench
• Hex Wrench Set (08469)
• 8-inch Adjustable Wrench (08467)
• 12-inch Adjustable Wrench (08468)
• 1/2-inch Wrench or 1/2" x 9/16” Combination Wrench (08476)
• 9/16-inch Wrench (08476) or 1/2” x 9/16” Combination Wrench (08476)
• Repair Kit: PAT-CCP-LS-0590-RK
IMPORTANT WARRANTY INFORMATION
Please note that components used on this equipment are made of specially developed,
high-strength material.
Only authentic Magnum Venus Plastech replacement parts are acceptable for
use with this equipment.
Use of unacceptable replacement parts will void our liability and warranty of this
equipment.
Please contact your Magnum Venus Plastech distributor for more information.
Lubrication:
Throughout this manual, directions are given for lubricating various parts of the Fluid
Section. These are the typical lubricants used:
If the part contacts resin, use MVP Red Grease (6706-2-1).
If the part is located where it will contact air, use Lubriplate
®
(08465).
Throat Seal Oil (TSL-3200) used in the oil reservoir of the pump.
Throat Seal Oil for use with ISO (TSL-ISO-800) 8 oz.
Grease for use with ISO (GR-ISO-100) 1 oz.
DANGER: FIRE AND EXPLOSION HAZARD. Never use any lubrication on the
components of the catalyst system. Contact your catalyst manufacturer for additional
material handing information.
