PAT-CCP-LS-0590 Chop Check Fluid Section Manual
Rev. 02/2012 Page | 15
Introduction:
This manual, the Patriot Chop Check Manual, provides information you need to
perform simple maintenance and repair on your equipment.
• Step-by-step assembly and disassembly procedures are included.
Please read the manual carefully. Follow the steps in the order given, otherwise you
may damage the equipment or injure yourself. Be prepared by having a clean work
area, tools and current parts drawing available.
DANGER: Always wear proper safety equipment, including eye protection and
gloves when performing service and repair on this equipment.
When removing
Pump Fluid Section, Hoses and Resin Surge Chamber, be sure to bleed off fluid
pressure from the system before disconnecting. Release Surge Chamber charge
before removing Surge Chamber. System may be under pressure and cause
injury.
This manual covers the following Fluid Section assembly:
• PAT-CCP-LS-0590 Patriot Chop Check Fluid Section
• PAT-CCP-LS-0590-SS Stainless Steel Chop Check Fluid Section
This manual covers the following Pump assembly:
• PAT-CCP-PA-1300-SS Stainless Steel Chop Check Pump Assembly
• PAT-CCP-PA-2300 Patriot Chop Check Pump Assembly
Note: The Fluid Section can be rebuilt in place or easily removed and taken to a
workbench. Flushing the fluid section with suitable cleaning agent can make the
rebuild process much easier.
During Disassembly . . .
As you disassemble the equipment, lay out the components in the correct order and
direction. This will help you to reassemble them.
