Meter prover operation-comprehensive – Liquid Controls SP1200 User Manual
Page 2
METER PROVER OPERATION-COMPREHENSIVE
WARNING
Never drop any component of the prover system-carefully place each component in desired location.
The Temperature Probe MUST be removed before installation or removal of transition piping. The
probe is easily damaged by any type of shock.
All prover runs are to be made using temperature compensation.
PROCEDURES
Assemble prover piping on the discharge of the trailer to be proved. The prover MUST be
supported.
Install the temperature probe.
Connect all wiring to the prover.
Cool down piping by allowing liquid to flow. You may pump off for a short period of time to
complete cool down.
DURING COOL DOWN
Note the calibration factor entered on the trailer’s totalizer.
Set up the SP1200 for the prover run.
NOTE: Numerical data will be typed by pressing the desired digit keys. If a mistake is made, press
the “CLEAR/FEED” key to erase the entire line typed, or press the “
← ” key to erase the last number
typed. Press the “ENTER” key when the number is correct.
