Digital Hybrid Wireless™ Modular Receiver System
Setting Up the Venue Receiver Using VRpanel
Once the LecNet2 ™ software and USB drivers have
been installed, the Venue receiver can be configured
with a software interface and a computer using a Win­
dows ® 2000, XP or Vista TM operating system.
VRpanel is an intuitive software package that simplifies
the setup and operation of the Venue receiver. This sec­
tion of this manual is limited to the basic setup and con­
figuration. More detailed explanations concerning usage
and configuration are contained in the online Help.
The online Help also documents the serial commands
used by external devices, including AMX ® and Crestron ®
remote control systems, that can be used to control the
Venue system.
Opening VRpanel with USB Port
1. Lauch VRpanel from Start/All Programs/LecNet2,
or from a shortcut you create yourself.
2. When the “How to Begin” dialog box appears, select
I would like to Add VR detected via USB and
click OK.
Opening VRpanel with a COM Port
1. Lauch the VRpanel software from Start/All Pro­
grams/LecNet2, or from a shortcut you create
yourself.
2. Click on I would like to begin with a Blank con­
figuration.
3. Click on Add via COM1 (or whichever COM port
is to be used) under the Configuration menu to the
receiver to the configuration.
3. The Add VR(s) via USB dialog lists the ID & Serial
Number of all Venue Systems connected to the VRpanel Main Window
computer via the USB. Select the VR (Venue receiv-
The Main Window shows all connected Venue receivers
er) to be monitored or configured and then click OK
with real time information for each receiver module.
to add the receiver to the VRpanel configuration.
Receiver information
