© Sealevel Systems, Inc. - 6 - ACB-MB+4.PCI User Manual
120-Pin Connector Pin Out
The ACB-MP+4.PCI has a 120-pin high-density connector and includes a cable
(Item# CA339) that breaks out to four (4) DB25 male connectors. The pin outs for
RS-232, RS-485, RS-530, RS-530A, and V.35 interfaces on the DB25 connectors
are listed on the following pages. For customers designing their own cable, the
mating 120-pin connector is Molex p/n 55032-1209. The pin out for the 120-pin
connector is listed below.
120-Pin Molex Connector
Port 1 Port 2 Port 3 Port 4
DB25M
Connectors
1 31 61 91 NC
2 32 62 92 14
3 33 63 93 2
4 34 64 94 15
5 35 65 95 3
6 36 66 96 16
7 37 67 97 4
8 38 68 98 17
9 39 69 99 5
10 40 70 100 18
11 41 71 101 6
12 42 72 102 19
13 43 73 103 7
14 44 74 104 20
15 45 75 105 8
16 46 76 106 21
17 47 77 107 9
18 48 78 108 22
19 49 79 109 10
20 50 80 110 23
21 51 81 111 24
22 52 82 112 11
23 53 83 113 12
24 54 84 114 NC
25 55 85 115 13
26 56 86 116 NC
27 57 87 117 NC
28 58 88 118 NC
29 59 89 119 NC
30 60 90 120 NC
