© Sealevel Systems, Inc. - 10 - ACB-MB+4.PCI User Manual
Electrical Characteristics
Features
Configurable for RS-232, RS-422, RS-485, RS-530, RS-530A, or V.35
Z85230 Enhanced Serial Communications Controller (ESCC™) supporting
synchronous or asynchronous communications
Programmable electrical interface selection for EIA/TIA-232/530/530A/485 and
ITU V.35
Programmable options for Transmit clock as input or output
Software programmable baud rates
Data rates to 128K bps
Included cable with (4) DB25M connectors
X.21 and RS-449 serial interface capability with versatile cabling options
Specifications
Environmental Specifications
Specification Operating Storage
Temperature
Range
0º to 70º C
(32º to 158º F)
-50º to 105º C
(-58º to 221º F)
Humidity Range 10 to 90% R.H.
Non-Condensing
10 to 90% R.H.
Non-Condensing
Power Requirements
+5VDC @ 750mA
Dimensions
L W
6.53” 4.20”
16.58cm 10.69cm
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are
100% electrically tested. These printed circuit boards are solder mask over bare
copper with either Electroless Nickel Immersion Gold (ENIG) or Hot Air Solder
Leveled (HASL) finish.
