© Sealevel Systems, Inc. - 2 - ACB-MB+4.PCI User Manual
Before You Get Started
What’s Included
The ACB-MB+4.PCI is shipped with the following items. If any of these items is
missing or damaged please contact Sealevel for replacement.
Item# 5402 – ACB-MB+4.PCI Adapter
Item# CA339 – 120-Pin Molex to (4) DB25M Breakout Cable, 36” in Length
Item# SSI-CD – Sealevel Software CD with SeaMAC drivers
Optional Items
Depending upon your application, you are likely to find one or more of the following
items useful for interfacing the ACB-MB+4.PCI to real-world signals. All items can
be purchased from our website (
http://www.sealevel.com ) or by calling 864-843-
4343.
CA104 – A 6’ serial extension cable with one DB-25 female connector and one
DB-25 male connector, pinned one-to-one.
CA107 – a 10” shielded cabling adapter with a DB-25F (RS-530) to a DB-37M
(RS-449 DTE). RS-530 is replacing RS-449 in Telecom applications, but there is
still a very large installed base of equipment that still uses the RS-449 pin-out.
Both standards use RS-422 to define the electrical specifications and are
interchangeable via this adapter cable.
CA159 – A 6’ shielded cable with a DB-25 female connector (RS-530 pin out) to
a DB-15 male connector (X.21 pin out) that converts the standard DB-25
implementation of RS-530 or RS-422 to the ITU-T X.21 standard.
CA174 – A 6’ serial extension cable with twisted data pairs for increased data
integrity. Recommended for high-speed RS-530 connections.
CA178 – A 6’ shielded cable with a DB-25 female connector to an ITU-T ISO-
2593 style connector (V.35) that converts the Sealevel DB-25 implementation to
the ITU-T V.35 mechanical standard.
