2
Fig. 2 - Sensor Fig. 3 - Cable Gland
Lock Nut
Body
Nut
Mounting
Brackets
Horizontal
Adjustment
Screw
Vertical
Adjustment
Screw
Lens Cover
Terminal
Block
Mounting Screws
(not included). Be
sure to use flat-
head, flush
mounting screws.
Side
Bracket
Attach bracket
to wall. Then
slide sensor
onto bracket.
Fig. 4 - Sample Installations
Fig. 5 - Mounting
Flush Mount
Perpendicular Mount
Gates
Vehicle detection Factory assembly line
W e m ec
l
o
Store front door
Main
entrance
door
Garage
door
