www.ramsetinc.com 5
RAMSET
RAM 2000 UL - RAM 2100 UL - RAM 2200 UL
GENERAL SPECIFICATIONS:
RAM 2000 UL
- 2100 UL
- 2200 UL
*EMERGENCY RELEASE: Pull down release disengages gate from motor so it can be
opened manually.
OPTIONAL ACCESSORIES:
BBS: Battery Back-up System.
RPI-120: Ramset Power Inverter. (on "RAM 2000 UL" only)
I M P O R T A N T :
Always shut power Off
before attempting to
use the emergency
release.
MODEL: RAM 2000 UL RAM 2100 UL RAM 2200 UL
Max. Gate Length: 20 feet 20 feet 20 feet
Max. Gate Weight: 450 lbs. 550 lbs. 550 lbs.
Cycles: Continuous Continuous Continuous
Aerovox 65µƒ, 240V, 50/60Hz. Aerovox 65µƒ, 240V, 50/60Hz. Aerovox 65µƒ, 240V, 50/60Hz.
Capacitor: protected S 1000AFC protected S 1000AFC protected S 1000AFC
Application: Commercial Commercial / Industrial Commercial / Industrial
Finish and
Construction: 10 Ga Gold/Zinc plated metal 10 Ga Gold/Zinc plated metal 10 Ga Gold/Zinc plated metal
Continuous Duty 1/2 Hp 120 VAC 4.5 amp. 3/4 Hp 120 VAC 8.5 amp. 1 Hp 220 VAC 4.5 amp.
Motor: 1625 rpm. 50/60Hz. 1625 rpm. 50/60Hz. 1625 rpm. 50/60Hz.
Operating Temperature: -10º F to 160º F -10º F to 160º F -10º F to 160º F
Gate Travel Speed: Approx. 90° opening in 14 sec Approx. 90° opening in 14 sec Approx. 90° opening in 14 sec
Power Failure * Pull down release and open manually. * Pull down release and open manually. * Pull down release and open manually.
Release: Optional battery back-up system/Inverter. Optional battery back-up system. Optional battery back-up system.
Chassis Base Dimension: W: 17" x L: 22 1/8" W: 17" x L: 22 1/8" W: 17" x L: 22 1/8"
Overall Dimensions: H: 10" - L: 143" - W: 13" H: 10" - L: 143" - W: 13" H: 10" - L: 143" - W: 13"
Shipping Weight: 125 lbs. 135 lbs. 135 lbs.
WARNING: Do not exceed the specifications.
Pull
Down
