Controlled Products Systems Group RAM2000 User Manual
Page 21
19
www.ramsetinc.com
RAMSET
RAM 2000 UL
- 2100 UL
- 2200 UL
BILL OF MATERIAL FOR:
RAM 2000 UL - RAM 2100 UL - RAM 2200 UL
1
50-005
10 Ga Zinc Plated Metal Chassis
1
1
1
2
50-018
Spring Load Bracket
1
1
1
3
50-020
6 1/4" Limit Switch Shaft
1
1
1
4
50-021
Polyethylene Cover
1
1
1
5
50-028
Speed Reducer Size 40/40:1 Gear Ratio
1
1
1
6
50-033
1/2 Hp 115 VAC Electric Motor
1
7
50-034
3/4 Hp 115 VAC Electric Motor
1
8
50-035
1 Hp 220 VAC Electric Motor
1
9
50-039
20 Pin Edge Connector
1
1
1
10
50-042
7" Guide Roller Shaft
2
2
2
11
50-051
41 b 15 x 3/4" Sprocket
1
1
1
12
50-058
3 1/2" UHMW Chain Guide Wheel
1
1
1
13
50-064
1" Tension Spring
2
2
2
14
50-066
Limit Switch Nut
2
2
2
15
50-069
Limit Switch 00h-3
2
2
2
16
50-070
5/8" x 2" Cast Iron Pulley
1
1
1
17
50-071
5/8" x 2 1/2" Cast Iron Pulley
1
1
1
18
50-087
#41Chain 20'
1
19
50-088
#40 Chain 20' (for 3/4" and 1 Hp only)
1
1
20
50-091
#6 x 1" Machine Screw
4
4
4
21
50-092
3/8-16 x 1 1/2" Hex Head Bolt
2
2
2
22
50-095
5/16-18 x 3/4" Hex Head Bolt
10
10
10
23
50-096
5/16" Split Lock Washer
12
12
12
24
50-097
5/16" Flat Washer
18
18
18
25
50-101
3/8" Split Lock Washer
5
5
5
26
50-102
1/4-20 Hex Head Nut
4
4
4
27
50-103
3/8-16 Hex Head Lock Nut
11
11
11
28
50-104
5/16-18 Hex Head Nut
4
4
4
29
50-105
#6 Hex Head Nut
4
4
4
30
50-107
#6 x 3/8" Machine Screw
8
8
8
31
50-108
1/4 " Flat Fender Washer
4
4
4
32
50-137
UHMW Trolley
1
1
1
33
50-138
Metal Trolley
1
1
1
34
50-139
Arm Release
1
1
1
35
50-140
Front Swivel Bracket
1
1
1
36
50-141
#700 Bracket
2
2
2
37
50-142
3 1/2" x 108" Rail
2
2
2
38
50-151
Warning Sign for Gate
2
2
2
39
50-168
Horn Alarm
1
1
1
40
50-265
3/16" x 3/4" Key Way
3
3
3
41
50-273
4L V Belt # 200
1
1
1
42
50-295
#8 Self-Tap Sheet Metal Screw
2
2
2
43
50-299
Radio Receiver Terminal
1
1
1
44
50-303
Ram 2000 Instruction Manual
1
1
1
ITEM
PART #
PART DESCRIPTION
RAM 2000 UL
RAM 2100 UL
RAM 2200 UL
