1
www.ramsetinc.com
RAMSET
RAM 2000 UL
- 2100 UL
- 2200 UL
TABLE OF CONTENTS
Important Safety Requirements & Instructions …………………………………………….........…….………… 1
Responsibilities of Installers and Technicians ………………………………………………………….………… 2
Important Safety Requirements by UL Standards …………………………………….………………………… 3
Classes of Vehicular Gate Operators - Recommended Electrical Connection ……...……………..………… 4
General Specifications (RAM 2000 UL, RAM 2100 UL and RAM 2200 UL) ……………………....………………. 5
Installation Specifications / Sample Gate Hardware ………………………………………………..………… 6-7
Special Requirement and Safety Edge Sensor Placement ……………..…………………………....………… 8
Photo Eye Sensor Placement and Safety Loop System Installation (Begin) .…..…………………………….. 9
Safety Loop System Installation (Continuation ) ……………………………………………………….………….10
Pushbutton Controls - Hookup Electrical Power - Gate Travel Adjustment …..…………………...…………11
Dip Switch Configuration …………………………………………………………………………….…………12-13
Terminal Strip Connection for Optional Accessories………………………………...............…...…………14-15
Ramset "Intelligate" Control Board ………………………………………………………....………….………… 16
Wire Board Connections ………………………………………………………………………………...…………17
Exploded View…………………………………………………………….…....……………………..……………. 18
Bill of Materials ……………………………………………………………………………………….………… 19-20
Gate Entrance Safety Precautions …………………………………………………………………….………… 21
Troubleshooting Table ……………………………………………………………………………..........………… 22
Ramset Optional Accessories ………………………………………………………………………….………… 23
Important Information for The Homeowner………………………………..........…………………….………… 24
IMPORTANT SAFETY REQUIREMENTS & INSTRUCTIONS
WARNING To reduce the risk of injury or death:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Never let children operate or play with gate controls.
Keep the remote control away from children.
3. Always keep people and objects away from the gate.
NO ONE SHOULD CROSS THE PATH OF THE MOVING
GATE.
4. Test the Vehicular Gate Operator monthly. The gate
MUST reverse on contact with a rigid object or stop
when an object activates the non-contact sensors.
After adjusting the limit of travel, retest the Vehicular
Gate Operator. Failure to adjust and retest the
Vehicular Gate Operator properly can increase the
risk of injury or death.
5. Use the Emergency Release only when power switch
or circuit breaker has been turned off. Using the Emer-
gency Release during a power failure can be a
hazard if power is abruptly restored.
6. KEEP GATES PROPERLY MAINTAINED. Read the
Owner’s Manual. Have a qualified service person
make repairs to gate hardware.
7. The entrance is for vehicles only. Pedestrians must
use separate entrance.
8. SAVE THESE INSTRUCTIONS.
006.03.27
WARNING:
Do not install this gate operator if you do not have experience or appropriate
training with gate operators.
