January, 200 4
412 O pe rator And
455 D Control Panel I nst allatio n M anual
Parts List
412 Compact Operator
POS PART NO. DESCRIPTION
QTY
1
799360
Motor Housing, SX top section
1
1
799359
Motor Housing DX top section
1
2
713009
Manual Release Key, 412
1
3
7171345
Flange, Protective Cover, 412 SX
1
3
7171335
Flange, Protective Cover, 412 DX
1
4
N/A
Nickel Plated Self Tapping Screw (3.5 x 13 mm)
1
5
N/A
Self Tapping Screw (5.5 x 15 mm)
2
6
799358
Cylinder Collar
1
7
736060*
Cylinder Assembly New (Slide On)*
1
8
727148
End Cap, Protective Cover SX
1
8
727147
End Cap, Protective Cover DX
1
9
N/A
Nickel Plated Self Tapping Screw (3.5 x 9.5 mm)
3
10 2705
Capacitor For 115 v (25μf)
1
10 2707
Capacitor For 220 v (8μf)
1
11 727216
Protective Cover, 412
1
12 722298
Protective Cover Support, 412
1
13 N/A
Self Tapping Screw (5 x 18 mm)
4
14 716074
Motor Housing, Bottom Section
1
15 746030
Stator (motor) for 220 v
1
15 746755
Stator (motor) for 115 v
1
16 746028
Rotor (motor)
1
17 710919
Strain Relief, 412
1
18 390009
Skin Pack, 412 (1 pack = 2 operators)
1
*Models Manufactured before 2000 used a screw in type cylinder assembly. The part
number for this type cylinder is 736039. The manufacture date is the NR number on
the sticker located on the top motor housing.
