Controlled Products Systems Group DL650 - Manual (Page 2)

2425 Pomona Rd.
Corona, CA. 92880
Revision F
TABLE OF CONTENTS OWNER REGISTRATION CARD
INTRODUCTION Thank you for purchasing a BASE Industries Digi-Lock access system.
Product Overview……………………………… 1 Please complete the following information and return this card by mail to
System Dimensions………………………….. 1 BASE Industries to properly register your new access system.
Safety Guidelines…………………………….. 2
INSTALLATION IMPORTANT NOTICE
Mounting The System……………………….. 2 Never allow this device to be installed within reach of an automatic vehicular gate operator
Grounding The System………………………. 2 or gate. It must be mounted in such a way that the user cannot come into contact with the
Powering The System………………………… 2 gate or the gate operator when the device is used. We recommend that the unit be installed
Basic Wiring Connections…………………… 3 a minimum of 10 feet away from any gate or gate operator.
Wiring Diagrams………………………………. 3
Circuit Board Diagram……………………….. 4
Auxiliary Open Wiring Connections………… 4 Owners Name: _____________________________________________
Time Clock Wiring Connections…………….. 4
Slave Keypad Wiring Diagram………………. 5 Mailing Address: _____________________________________________
PROGRAMMING City: ______________________ State: _______ Zip: ___________
Programming Entry Codes………………….. 6
Erasing Individual Entry Codes……………… 7 Phone: ____________________
Erasing All Entry Codes………….………….. 7
Programming Relay 1 Activation Time...…… 8
Programming Relay 2 Activation Time…….. 8 System Address: ____________________________________________
Programming Strikes And Out Feature …… 9
Programming Entry Code Length …………. 9 City: ______________________ State: ________ Zip: __________
Program Access Code (PAC)………………. 10
Verifying Program Access Code (PAC)……. 10 System Model: ______________
TROUBLESHOOTING Serial Number: ______________ Date Purchased: _______________
Troubleshooting Tips…………………………. 11
Purchased From: ____________________________________________
PARTS LIST
Parts List & Diagram…………………………. 12 Installed By: ________________________________________________
IMPORTANT NOTICE
If this system is used to activate an automatic vehicular gate operator, it must Please return this Owner Registration Card by mail to:
be mounted in such a way that the user cannot come into contact with the gate
or the gate operator when the device is used. We recommend that the unit be
2
