2 solid-state (form a) 12 output option, Solid-state (form a) 12 output option – CTI Products GPIO General Purpose I/O Interface User Manual
Page 20
GPIO Hardware Reference
Connectors
CTI Products, Inc.
6.3.2
Solid-State (Form A) 12 Output Option
Option
Position Signal
Front Panel
LED
J1 Pin
26 A
Out A1 +
A1
1 A
Out A1 -
27 A
Out A2 +
A2
2 A
Out A2 -
28 A
Out A3 +
A3
3 A
Out A3 -
29 A
Out A4 +
A4
4 A
Out A4 -
30 A
Out A5 +
A5
5 A
Out A5 -
31 A
Out A6 +
A6
6 A
Out A6 -
32 A
Out A7 +
A7
7 A
Out A7 -
33 A
Out A8 +
A8
8 A
Out A8 -
34 A
Out A9 +
A9
9 A
Out A9 -
35 A
Out A10 +
A10
10 A
Out A10 -
36 A
Out A11 +
A11
11 A
Out A11 -
37 A
Out A12 +
A12
12 A
Out A12 -
38 B
Out B1 +
B1
13 B
Out B1 -
39 B
Out B2 +
B2
14 B
Out B2 -
40 B
Out B3 +
B3
15 B
Out B3 -
41 B
Out B4 +
B4
16 B
Out B4 -
42 B
Out B5 +
B5
17 B
Out B5 -
43 B
Out B6 +
B6
18 B
Out B6 -
44 B
Out B7 +
B7
19 B
Out B7 -
45 B
Out B8 +
B8
20 B
Out B8 -
46 B
Out B9 +
B9
21 B
Out B9 -
47 B
Out B10 +
B10
22 B
Out B10 -
48 B
Out B11 +
B11
23 B
Out B11 -
49 B
Out B12 +
B12
24 B
Out B12 -
50 nc
25 nc
68-12068-100
20
