4.3.3.2 The Signal Connector:
The signal connectors are supported by the molex
®
KK .100" (2,54mm) Centerline Connector System.
A. J1 of MAIN AMP:
MATING CONNECTOR: molex
®
2695 Series .100" (2,54mm) Center Crimp Terminal Housing
(PART# 22-01-3175):
- red nylon housing.
-
15
positions.
- with polarizing rib.
CRIMP TERMINALS: molex
®
Crimp Terminals (PART# 08-55-0102):
- 15 microinch select gold plated.
-
brass.
B. J4 and J5 of SINE/RESOLVER PRE-AMP:
J4 has 7 pins and J5 has 5 pins and their corresponding mating connectors have 7 and 5 positions.
Their molex
®
part numbers are as follows:
- J4 MATING CONNECTOR PART NUMBER: 22-01-3077.
- J5 MATING CONNECTOR PART NUMBER: 22-01-3057.
