CXB1525 and CXB2040 MANUAL
8900 Zachary Lane N., Maple Grove, MN 55369 U.S.A. 10
1.3 SPECIFICATIONS:
This section contains the specifications for the brushless trapezoidal, sine/resolver and two or three
phase input current mode D.C. Servo Amplifiers. These specifications also include power supplies for the
amplifiers.
NOTE: All data in this section is based on the following ambient conditions: 120
o
F (50
o
C)
maximum. Forced air cooling.
1.3.1 STAND ALONE ONE AXIS AMPLIFIER:
The stand alone one axis amplifier contains a single amplifier module, a DC power supply, a cooling
fan, fusing and shunt regulator in a sheet metal enclosure. The shunt regulator within the DC power
supply has a 50W internal load resistor bank which bleeds off excess DC Buss voltage when decelerating
a large load inertia. An external shunt regulator resistor can be connected (Consult with factory).
NOTE: Customer must specify the input AC voltage (105-120VAC/205-250VAC) when ordering (see
chapter 3: model numbering), so that the proper fan can be installed.
1.3.1.1 Input and Output Power:
1.3.1.2 Signal Inputs:
Input Power/
Buss Voltage(B+)
Output Power
(current)
CXB1525
R.M.S. Peak R.M.S. Peak
120VAC/170VDC 15A 25A 20A 40A
240VAC/340VDC 10A 25A 15A 35A
CXB2040
Amplifier
Model
Signal Input Maximum
Voltage
(VDC)
Minimum
Impedance
S
Velocity Gain
Amp./Volt
Current Gain
Amp./Volt
CXB Series Differential ±13 10,000 15,000(min.) 0-5
CXB Series Single-ended ±13 10,000 15,000(min.) 0-5
