CXB1525 and CXB2040 MANUAL
8900 Zachary Lane N., Maple Grove, MN 55369 U.S.A. 22
4.3.2 Wire Size and Type:
IMPORTANT: To ensure safe operation, CONTREX strongly recommends that all wiring conform
to all local and national codes.
RECOMMENDED WIRE SIZE and TYPE:
MOTOR WIRES: 14AWG, shielded - STANDARD.
12AWG, shielded - HIGH POWER.
MOTOR CASE GND: Same as motor wires, or use metallic conduit.
MAIN POWER: Same as motor wires.
SIGNAL INPUT: 22AWG, twisted-pair, shielded.
LOGIC INPUTS/OUTPUTS: 22AWG, shielded with its return lead.
EXTERNAL TACHOMETER: 22AWG, twisted-pair, shielded.
RESOLVER OUTPUTS and
EXCITATION : 22AWG, three twisted-pairs, over-all shielded.
4.3.3 Connector Size and Type:
4.3.3.1 The Power and Motor Connector of the Stand Alone Amplifier:
 Motor - J2 of the Stand Alone Amplifier:
Mating Connector: PHOENIX CONTACT, COMBICON Plugs in 7.62mm
Pitch
(P/N: GMVSTBR 2.5/3-ST-7.62):
- with vertical plug-in direction to the conductor axis.
- 3 positions.
- Color: green.
 Power Input - J6 of the Stand Alone Amplifier:
Mating Connector: PHOENIX CONTACT, COMBICON Plugs in 7.62mm
Pitch
(P/N: GMVSTBW 2.5/4-ST-7.62):
- with vertical plug-in direction to the conductor axis.
- 4 positions.
- Color: green.
